WI-PCMS310GF-O

● Hardware version: V1
● 8*10/100/1000Mbps RJ45 PoE Ports
● 2*100/1000Mbps SFP Slots
● IP65 weatherproof enclosure
● Working temperature: -30~70℃
● All-in-one for easy installation
● Support Wi-Tek cloud management

Model

WI-PCMS310GF-O

Hardware Specifications

Interface

8*10/100/1000Mbps RJ45 Ports and 2 Gigabit SFP Slots

Interface Port Standard

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1x, IEEE 802.1q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w, IEEE 802.3ad, IEEE802.3af, IEEE802.3at

PoE Standard

PoE 802.3 af/at

PoE Ports

8, up to 30W

PoE Power Budget

110W

Power Supply

AC 100-240V 120W

Standby Power Consumption

10W

Switching Capacity

20Gbps

Packet Forwarding Rate

14.88Mpps

Jumbo Frame

10KB

MAC Address Table

8K, Auto-learning, Auto-aging

Fan Quantity

Fanless

RJ45 PoE Power Supply

Mode A 1/2(+)3/6(-)

Dimensions( W x D x H )

300*220*30mm

Net weight/gross weight (kg)

0.97Kg/1.37Kg

Reset Button

Press and hold the reset button until all port indicators are on, indicating that the reset is successful.

LED indicator

PWR: Off: No Power supply; On: The switch is powered on

SYSBlinking: the system works; Off: the system is starting or has no power

1~8 port: Off: The network is not connected

On: A 10/100/1000M network device is connected

Blinking: Data is being transferred

9~10 port: Off: No device is connected to the corresponding port.

On: Indicates the link through that port is successfully established at 1000Mbps.

Blink: Indicates that the Switch is actively sending or receiving data over that port.

Protection Level

Surge Protection: Differential mode ±4KV, Common mode ±6KV

Electrostatic Standard: Contact ±6KV, Air ±8KV

Protection class: IP65

Transmission Method

Store— Forward

Installation

Pole- Mounted

Environment

Operating temperature/humidity: -30°C ~ 70°C; 10%90% RH no condensation

Storage temperature/humidity: -40+80°C; 5%95% RH no condensation

Certification

CE, FCC, RoHS ,UKCA

Software Features





Spanning Tree

IEEE 802.1D -STP

IEEE 802.1w -RSTP

IEEE 802.1s -MSTP

BPDU Guard

STP Root Guard

Loop Detection







VLAN

Management VLAN

Private VLAN

Voice VLAN

Monitor VLAN

Q-in-Q

Protocol-Based VLAN

MAC-Based VLAN









Port

LACP

Static

EEE

Jumbo Frame

Error-Disable

Port mirroring (One-to-One Many-to-One Tx/Rx/Both)

Link Aggregation (Up to 8 aggregation groups and up to 8 ports per group)

Port Isolation









Security

IEEE802.1x AAA

ACL support L2+/L3/L4 IPv6 ACL

Dynamic ARP Protection

Broadcast Storm

RADIUS/TACACS+

RADIUS Authentication (RFC2138)

SSH v1.5/v2.0

Anti-DDoS Attack

DHCP Snooping





QoS

Ipv4 QoS (QCEs)

Ipv6 QoS (QCEs)

Priority Algorithm (WRR,Absolute Priority,DSCP & CS)

Class of Service (Port-Based,802.1p, CoS, DSCP, IP Priority, TCP/UDP IPv4/IPv6)

Bandwidth (Input /Output)



L2 Multicast

IGMP Snooping v1/v2/v3

MLD Snooping v1/v2

MVR









IPV6

Ipv6/IPv4

Ipv6 Web/SSL

Ipv6 SNTP

Ipv6 Telnet/SSH

Ipv6 Ping/Traceroute

Ipv6 TFTP

Ipv6 RADIUS/TACACS+

Ipv6 SNMP















Management

SNMP (v1, v2c, v3)

RMON ( 1, 2, 3 & 9 )

Firmware Upgrade

Configuration Export/import

DHCP Option 82

System Log Supports Event/Error Log

Manage Access Control (Console Port, SNMP, HTTP/HTTPS, Telnet,SSH)

LLDP (IEEE802.1AB)

LLDP-MED

UDLD

DNS Client

Traceroute

Ping

DDMI

NTP/ SNTP (RFC2030)









Advanced Features

ONVIF (ONVIF Detection, ONVIF Server(NLM) )

Batch Firmware Upgrading

Intelligent Network Monitoring

Abnormal Event Warnings

Automatic Device Discovery

Support Cloud Management

Support Remote Management

Support Cloud VLAN Configuration

Support Topology Display

Support Cloud Control Port Configuration
