Product

WI-PMS306GF-UPS-I

HARDWARE Version

V1

Interface

4 10/100/1000Mbps RJ45 Ports

2 1000Mbps SFP Slots

1 Console Port

PoE Ports (RJ45)

Port 1-2: 802.3bt PoE 60W

1/2/4/5 (+), 3/6/7/8 (-)

Port 3-4: 802.3af/at PoE 30W

1/2 (+), 3/6(-) or Passive 24V PoE: 4/5(+), 7/8(-)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

1000BASE-X: MMF, SMF 1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

Fan Quantity

Fanless

Power Consumption

120W (max. with PoE device connected) 5W Max (without PoE output)

Power Supply

For 12V Battery: DC 15-32V

For 24V Battery: DC 30-57V

Power Priority

Solar Power>DC>Battery

Solar Controller Input

≤32V(12V standard)

≤45V(24V standard)300W Max

Battery Type

Lead acid/lithium/lifepo4

Battery Input

12/24V 10A

Exchange Capacity

12Gbps

Packet Forwarding Rate

8.94Mpps

Mac Address Table

8k

Packet Buffer Memory

4.1Mb

Jumbo Frame

10240Bytes

Protection Level

6kV Lightning protection

6kV ESD Contact discharge

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

235×167×80mm

Switch Dimension

156×115×66mm

Gross Weight

1.43kg

Net Weight

1.28kg

Package Contents

1 x Industrial PoE Switch

1 x Screw Driver

1 x Quick Installation Guide

Working Temperature

-40℃～80℃

Storage Temperature

-40℃～70℃

Working Humidity

10%～90% RH non-condensing

Storage Humidity

5%～90% RH non-condensing

SOFTWARE FEATURES

Spanning Tree

IEEE 802.1D -STP, IEEE  802.1w -RSTP, IEEE  802.1s -MSTP

VLAN

Max 4K VLAN Groups, 802.1q Tagged VLAN, MAC-based VLAN, IP-based VLAN,  Protocol-based VLAN,
Selective QinQ, 802.1q-based VLAN, Voice VLAN

Port

LACP, Jumbo Frame, Port Shutdown,
Link Aggregation( Up to 8 aggregation groups and up to 8 ports per group),

Port mirroring( One-to-One  Many-to-One Tx/Rx/Both)

Security

IP-MAC-Port Binding, Support static and dynamic ARP, DHCP Snooping,
IEEE802.1x AAA, RADIUS/TACACS+, RADIUS, Port Isolation,

Port based authentication, Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
Broadcast/Multicast/Unicast Storm Control, Port MAC address filtering,

Access Control List

IP-MAC-Port Binding, Support static and dynamic ARP, DHCP Snooping,
IEEE802.1x AAA, RADIUS/TACACS+, RADIUS, Port Isolation,

Port based authentication, Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
Broadcast/Multicast/Unicast Storm Control, Port MAC address filtering,

QOS

Port-based (uplink and downlink traffic of a single port can be restricted), 802.1p-based Classification,
Support WRR, SP, WFQ, DSCP-Based Classification, ACL-Based Classification

L2 Multicast

Web-based GUI, Command Line Interface (CLI) through console port, telnet,SSH,
SNMPv1/v2c/v3 Trap/Inform  RMON (1, 2, 3, 9 )groups,

Password Recovery, SNTP, System Log, 802.1ab LLDP/LLDP-MED, UDLD, Traceroute,
 Ping, CPU Monitoring, Firmware upgrade,

 Configuration export/import, Support SNTP based IPv4 and IPv6, DHCP/BOOTP Client
