HARDWAR EFEATURES

WI-SG324F

Standards

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p

Interface

8 10/100/1000Mbps RJ45 Ports

16 1000Mbps SFP Slots

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

1000BASE-X: MMF, SMF 1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

LED Indicator

PoE/Link/Power

Fan Quantity

Fanless

Exchange Capacity

48G

Packet Forwarding Rate

35.7Mpps

Mac Address Table

8k

Power Adapter

AC IN : 100~240V

Packet Buffer Memory

12Mb

Jumbo Frame

10240Bytes

Port VLAN

No

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

515×300×95mm

Switch Dimension

440×220×45mm

Gross Weight

3.28kg

Net Weight

2.45kg

Package Contents

1 × Switch

1 × Power Cord

1 x Rack-mount Kit

1 x Rubber Feet

1 × Quick Installation Guide

Working Temperature

-10℃~55℃

Storage Temperature

-40℃~70℃

Working Humidity

10%~90% RH non-condensing

Storage Humidity

5%~90% RH non-condensing
